SolidCivil, Ontario Standards Edition
SolidCivil, Ontario edition – Civil 3D template for Ontario's Design Standards
The SolidCivil, Ontario edition product is a complete toolset for Civil 3D, adapted to Ontario’s design standards. These tools are:
- Designed by professionals who understand the need to address the specific design requirements for the Ontario Civil infrastructure industry. In this kit, users will have access to key components for Civil 3D that will help drive engineering projects that meet Ontario specifications and standards.
- Created to streamline the work of drafters, civil technicians, and engineers by incorporating Civil 3D’s best practices and most useful tools, minimizing manual and repetitive tasks.
SolidCivil Ontario Includes:
Access to a library of standard pipe sizes and standard structure types and sizes based on Ontario manufacturers and OPSD specifications.
Includes a collection of standard pressure pipe sizes based on IPEX products as well as a custom Steel material catalogue.
Access to the Transportation Association of Canada (TAC) Standards which are applicable across Canada.
Includes Curb subassemblies that follow the OPSD 600 series curbs.
Access to standard template that incorporates predefined parts lists specific to the OPSD gravity pipes, structures and IPEX pressure pipe catalogs, TAC Standards, and defines the typical objects and labels styles used in the Ontario civil industry.
This Sheet Set Template is a .dst file that is dynamically linked to custom title blocks for efficient plan and profile sheet generation.
Through the Sheet set Manager, design/drafters will now automatically fill title blocks for all their plan layouts and apply changes to all of them simultaneously during an ongoing project, saving hours in normally manual and repetitive tasks.
Use tool palettes for clear and accessible design elements right at your fingertips.
These custom tool palettes centralize most categories of AutoCAD objects used by the MTO (texts, blocks, hatches, polylines, and multi-lines) with clear and comprehensible descriptions, classified in both themes and object types, and that automatically place the created objects on the right layer.
If you are interested in learning more about our SolidCivil, Ontario Edition – Civil 3D template for Ontario’s Standards, or to schedule a FREE Technical Discovery, fill out the form below:
