Civil 3D: 2024.1 Update

The Civil team has updated the 2024 release and there are many cool new features. The Civil 3D updates include the AutoCAD update, but they don’t include the Map 3D update, so don’t forget to install that too.

Use Autodesk Access to install it or go to manage.autodesk.com and download it. Read on to find out more.

Official documentation for the Civil 3D 2024.1 update

Official documentation for the Map 3D 2024.0.1 update

Official documentation for the AutoCAD 2024.1 update

This is not an exhaustive list; please refer to the documentation for a complete list.

• Subassemblies

• • Import custom subassemblies without creating a tool in a palette.

• • Add subassemblies from the Prospector.

• • • Replace a subassembly by selecting a new PKT file.

•  Corridors

• • Create transitions across regions.
  • Copy and paste transition sets.
  • Better highlighting to identify areas in a transition.
• ArcGIS
  • Save back changes to AutoCAD objects.
  • Improved support for arcs
  • Improved performance.
  • Layers are alphabetically sorted.
• Pressure Networks
  • Pipe runs are less likely to become detached from their underlying pipe run alignments. Added warning messages that are displayed when the pipe run status is not correct after editing the pipe run.
  • Move and rotate pipe runs with AutoCAD MOVE and ROTATE commands.
  • Property set compatibility.
  • Automatically swap a tee for a wye when gip editing the pipe run.
• Gravity Networks
  • Connect pipes and structures to parts within other networks.
  • The Text-For-Each component can now be added to band styles.
• Project Explorer
  • New Subassembly category with many new and usable options.
  • Export slope patterns to 2D.
• Rail
  • Added the ability to create cant on spiral or tangent entities by adding user-defined curves in the Cant Curve Manager dialog box.
• API
  • New content for corridor transitions and gravity networks.
• Dynamo
  • Core updated to 2.18.
  • Player updated to 3.0.
